Cambridge Audio Alva Duo MM/MC Phono Amplifier

Duo
MM / MC Phono Amplifier with Ear Amplifier

Take every inch of detail from your vinyl records. This is our highest quality MM / MC phono amplifier with ear amplifier; Duo phono amplifier.

Maximum power consumption
10W

Phono support
Moving Magnet (MM) / Moving Coil (MC)

Gain at 1KHZ
MM: 39dB | MC: 60dB

Nominal output
300mV

Sensitivity of nominal output
MM: 3.35mV | MC: 305uV

EQUIVALENT INPUT NOISE (A-WEIGHTED)
MM: ~0.09uV | MC: ~0.08uV

RIAA curve accuracy
+/- 0.3dB 30Hz-50Hz

S/N ratio of ground input (20HZ-20KHZ BW)
MM: >90dB | MC: >70dB

THD+N 1KHZ (20-20KHZ BW)
MM: <0.0025% | MC: <0.20%

input resistance
MM: 47k Ohms | MC: 100 Ohms

Input capacitance
100pF

Overload margin
>30dB

Crosstalk at 10KHZ
MM: >85dB | MC: 75dB

Dimensions (width X height X depth)
48 x 215 x 159 mm (1.9 x 8.5 x 6.2")

weight
0.95kg (2.1lbs)
