Ortofon 2M Black Cartridges (Free Local Delivery)

The Shabata-type tip design used by the previous high-end model MC Jubilee is selected to enjoy better high-frequency response.

The newly designed Lexan DMX piano black super hard material is used as the cartridge shell

Output 5.5mV

Weight 7.2g

It is recommended to input capacitive reactance 150-300F

Features

- The 2M Black is graced with a Shibata diamond which slim, highly polished profile allows an exceedingly wide contact area to the groove walls and ensures notably detailed reproduction throughout the spectrum, including even the most high frequency groove information.
- The cartridge body is manufactured from Hopelex, an environment-friendly material which ensures high rigidity while eliminating unwanted resonances.
- The 2M Black uses a special upgraded engine, featuring split pole pins with a silver plated copper wire.

We have optimized the design for ease of mounting the cartridge, and the weight and size to fit the most common turntables on the market today. The 2M Series provides excellent compatibility when used in an assortment of playback systems and with a wide variety of phono preamps.

The Shabata-type tip design used by the previous high-end model MC Jubilee is selected to enjoy better high-frequency response.

The newly designed Lexan DMX piano black super hard material is used as the cartridge shell

Output 5.5mV

Weight 7.2g

It is recommended to input capacitive reactance 150-300F

Output voltage at 1000 Hz, 5cm/sec.  -  5 mV
Channel balance at 1 kHz  -  1 dB
Channel separation at 1 kHz  -  26 dB
Channel separation at 15 kHz  -  15 dB
Frequency response  -  20-20.000 + 2 / - 0 dB
Tracking ability at 315Hz at recommended tracking force  -  80 µm
Compliance, dynamic, lateral  -  22 µm/mN
Stylus type  -  Nude Shibata
Stylus tip radius  -  r/R 6/50 µm
Tracking force range  -  1.4-1.7 g (14-17 mN)
Tracking force, recommended  - 1.5 g (15 mN)
Tracking angle  -  20°
Internal impedance, DC resistance  -  1.2 kOhm
Internal inductance  -  630 mH
Recommended load resistance  -  47 kOhm
Recommended load capacitance  -  150-300 pF
Cartridge colour, body/stylus  -  Black/Black
Cartridge weight  -  7.2 g
